Applications:
• For fastening of FQ channels to base material
Advantages
• Oblong hole for fine adjustment along the
channels by 5mm, 10mm, 15mm, 20mm
• Suitable for both simply supported beams and
cantilever applications
• Robust design for increased load capacity
Technical data:
Material
Q235B–GB/T700–1988
Surface finish
Electro galvanized, AVG. 13μm – for dry indoor use only
Hot dip galvanized, AVG. 55μm – for C3 outdoor use
