Applications:
• For fastening of FQ channels to base material


Advantages

• Oblong hole for fine adjustment along the channels by 5mm, 10mm, 15mm, 20mm

• Vertical channels can be installed close to wall

• Robust design for increased load capacity
Technical data:
Material
Q235B–GB/T 700

Surface finish
Electro galvanized, AVG. 13μm – for dry indoor use only
HDG, AVG. 55μm+ for C3 outdoor use
